Share |      THE EXPERTS IN RON'S FUEL INJECTION NORMALLY ASPIRATED, NITROUS ASSISTED AND SUPERCHARGED APPLICATIONS!

Yes, you can run the engine
on pump gasoline with this plate
included as part of the Primer Plus!



IDLE AND DRIVE ON GASOLINE with the PRIMER PLUS SYSTEM!

The PRIMER PLUS system is the standard in priming and gasoline idling on the market today.  The Primer Plus system is extremely versatile and can be used in a number of ways including the below.

  • As a basic priming system for starting the engine easily. The equally distributed mist of fuel from the specially designed spray bar results in excellent cold starting capabilities for your alcohol engine.

  • It can be used as a gasoline idling system to aid in quickly warming the engine and driveline components on race day or for routine weekly maintenance at home. The engine will warm the engine to operating temperature of 155*-160* in minutes without using any alcohol.

  • The system can be used for all of the race car's activities from the pits, to the burnout box and back to the trailer after a pass.  It can also be used at the end of the day to flush the alcohol out of the engine.

  • It can be used with mechanical fuel injection units as well as carburetors.





BASIC PRIMER SYSTEM
  IF YOU JUST WANT EASY STARTING...

If the Primer Plus isn't currently in your budget you can purchase the Basic Primer for simple, easy starting. This system uses an injector placed in the neck of your intake manifold or in an existing spacer plate.

At a later date you can upgrade this system to the capabilities of the Primer Plus for an additional charge.

BASIC PRIMER SYSTEM - $235
This Basic Primer System (above) utilizes a one quart fuel cell, electric fuel pump, fuel solenoid, 40” injector hose, non-aerated nozzle  body, nozzle jet and a momentary switch.  The injector is plumbed into the neck of your manifold (or a spacer plate) and is used for adding gasoline to the plenum of the engine to aid engine start-ups.  Add $75 for a dual throttle body or hat-style system.  Add $100 if you wanto to upgrade to a one gallon fuel cell.


PRIMER PLUS SYSTEM - $460
This system also comes standard with a one quart fuel cell, electric fuel pump, fuel solenoid and 40” injector hose.  In place of the injector is a ¾” CNC aluminum plate that is utilized between your manifold and throttle body that features a custom spray bar/injector and needle valve assembly.  With this and the use of a toggle switch (provided) the system can be used to not only start the engine but idle the engine and drive the car on gasoline.  When ordering please specify what type of throttle body or carburetor you are going to utilize it with.  Idle time with the one quart cell is 6-8 minutes depending upon how the system is adjusted.  If you wish for larger fuel capacity you can delete the standard cell and add a one gallon fuel cell for an extra $100.  Add $140 for a dual throttle body system.  Add $100 if you want to upgrade to a one gallon fuel cell.



PRIMER PLUS CONVERSION - $235
If you already own a Basic Primer and wish to upgrade it to the Primer Plus this is for you.  This kit features same ¾” CNC plate, custom spray bar/injector assembly, needle valve assembly and toggle switch used in the Primer Plus.  When ordering please specify what type of throttle body or carburetor you are going to utilize it with.


“ENDERLE” PRIMER PLUS - $616
The "Enderle" Primer Plus (below) is used on hat-style injection units that utilize a 6-71 and 8-71 bolt pattern (13.25”).  It includes a one quart fuel cell, electric fuel pump, fuel solenoid, 40” injector hose, a 3/4” CNC aluminum plate with dual custom spray bar/injector, needle valve assembly and a toggle switch.  This can be used to not only start the engine but idle the engine and drive the car on gasoline.  If you already own a Basic Primer the “Enderle” Primer Plus Conversion is $364.  If you wish for larger fuel capacity you can delete the standard cell and add a one-gallon fuel cell for an extra $100.

INDIVIDUAL COMPONENTS FOR PRIMERS
One Quart JAZ Fuel Cell $65

One Gallon JAZ Fuel Cell $145
Low Volume Fuel Pump $80 (when available)
Heavy Duty Solenoid $85 (when available)
1/8” NPT x 1/8” NPT Fitting $6
40” Injector Hose $31
Basic Primer Non-Aerated Nozzle Body $21.50
Basic Primer Nozzle Jet $9.50
Custom Primer Plus Spray Bar/Injector Assembly $114.92
Needle Valve Assembly (includes -3AN Female to 1/8” NPT fitting) $71.35
-3AN Female x 1/8” NPT Fitting $13.44
